Low-Voltage Switchgear

Smart Arc Welding Machine Switchboard

The arc welding machine distribution board is specifically designed to safely distribute electrical power to arc welding machines. It ensures stable voltage supply, protects against overcurrent, and provides a secure connection for welding equipment. Built to withstand the demanding conditions of welding environments, this switchboard is an essential component for ensuring the safe and efficient operation of welding systems on construction sites and industrial workshops.

contact us Prev ProductNext Product

Standard Capacity

Material	Metal
Origin	China
CQC Certificate No.	CQ02010010301448623
Electric Shock Protection Category	Class I
Enclosure Protection Rating	IP43-IP66
Second-layer Door Protection Rating	IP21
Pollution Degree	3
Rated Voltage	380V
Rated Insulation Voltage	660V
Rated Impulse Withstand Voltage	6kV
Rated Frequency	50Hz、60Hz
Rated Current of Main Busbar	100A
Rated Short-Time Withstand Current of Main Busbar	3kA
Rated Peak Withstand Current of Main Busbar	4.5kA
Rated Current of Main Switch	100A
Rated Limiting Short-Circuit Breaking Capacity of Main Switch	3kA
Rated Operating Short-Circuit Breaking Capacity of Main Switch	3kA
Number of Outgoing Circuits	1 circuit

Product Features

Optimized Power Distribution:

The smart arc welding machine distribution board ensures the efficient and reliable distribution of power to multiple welding machines, ensuring that each machine gets the right amount of power for optimal performance.
Smart Monitoring and Control:

Integrated with smart technology, the distribution box allows users to monitor and control the power supply remotely, track usage, and analyze performance in real-time, improving operational efficiency.
Overload and Short-Circuit Protection:

Equipped with overload protection, short-circuit protection, and surge protection, the box prevents electrical damage and ensures the safety of the welding machines, operators, and work environments.
